显卡规格

规格方面，影驰的这张RTX 3060 Ti金属大师 OC跟公版的RTX 3060 Ti大体是相同的。4864个CUDA核心、152个第三代TensorCore、38个第二代RTCore、8GB的GDDR6显存，显存带宽同样是448GB/s。不同的地方在于这张3060ti金属大师是OC的版本是出厂预超频了，它的频率比起公版提高了60MHz。TGP方面，也自然提升了20W。

预览var tableid = settableid(); document.write(''); Table().init({ title: "显卡规格", header: ["型号","影驰 RTX 3060 Ti 金属大师 OC"], width: '70%', columnWidth: 'MAX', //表格单元宽度，"MAX"最大内容显示，""AVG"平均，"AUTO"自动，指定[15,16,20] id: tableid, data: [ ["核心代号","GA104-200"], ["晶体管数目(亿)","174"], ["核心面积(mm2)","392.5"], ["制程 (nm)","8"], ["GPCs","5"], ["SMs","38"], ["CUDA Cores","4864"], ["Tensor Cores","152（第三代）"], ["RT Cores","38（第二代）"], ["纹理单元","152"], ["光栅单元","80"], ["基础频率(MHz)","1410"], ["Boost频率(MHz)","1720"], ["单精度浮点性能 (TFLOPS)","16.2"], ["显存","8GB GDDR6"], ["显存数据速率(Gbps)","14"], ["显存位宽(bit)","256"], ["显存带宽 (GB/s)","448"], ["视频接口","HDMI 2.1×1DisplayPort 1.4×3"], ["PCI-E","4.0"], ["TGP (W)","220"], ["推荐电源(W)","650"], ["体型设计","2槽",], ["供电接口","8 Pin"], ["售价","3199元"] ] });测试平台我们马上拿这张影驰的RTX 3060 Ti 金属大师 OC和公版的RTX 2080 Super先跑一个理论测试，这次的测试平台是以Intel的Core i7-10700K以及32GB的DDR4 3600MHz内存搭建的。

预览var tableid = settableid(); document.write(''); Table().init({ align: 'left', width: '70%', padding: '8px 15px', header: ["测 试 平 台", ""], columnWidth: 'MAX', //表格单元宽度，"MAX"最大内容显示，""AVG"平均，"AUTO"自动，指定[15,16,20] id: tableid, data: [ ["硬件平台"], ["CPU","Intel Core i7-10700K"], ["主板","微星 Z490 Godlike"], ["内存","芝奇 皇家戟 DDR4-3600 16GB*2"], ["硬盘","影驰 HOF Pro PCIe M.2 2TB SSD"], ["散热器","雅浚 ProArtist Gratify 3"], ["电源","海盗船 HX1000i"], ["软件配置"], ["操作系统","Microsoft Windows 10 2004 64-bit"], ["驱动","Geforce Driver 457.40"] ] });基准性能测试在3D Mark的6个测试项目里面，RTX 3060 Ti有着平均6%左右的优势，稍微战胜了RTX 2080 SUPER。领先优势最大的是测试DX11的Fire Strike Ultra以及测试DX12 4K性能的Time Spy Extreme，差距在10%左右。

而同样是2K性能的测试项目，在DX11的Fire Strike Extreme中RTX 3060 Ti领先RTX 2080 SUPER 8%，而在DX12的Time Spy当中差距就不太明显，RTX 3060 Ti只有5%的优势。至于代表光追性能的Port Royal测试两者的表现几乎一模一样。1%的差距，基本可以当作是误差了。

预览var title_text = "3DMark Benchmark（DX12）"; // 标题文字热管 var subtitle_text = "www.expreview.com | 数值越大越好 "; // 副标题文字 var unit_text = "分 "; //单位 var leftside = "8%"; //左边空白 var topside = 50; //每组间距 var mblur = 0.05; //模糊效果 var bgopacity = 0; //背景透明度，0为全透明 var mysort = 0; //是否排序 var myper = 1; //是否显示百分比 var mylengend = true; //是否显示图例 var toplegend = 50; //图例上端空白 var labelcolor = '#fff'; // 标签文字颜色 var legendwidth = '90%'; //图例宽度 var titlecolor = '#222'; //标题文字颜色 var barheight = 35; //柱高度,当为7倍数时，不显示刻度线 var bargap = 3; //柱间距,相当于百分值，即2% var xaxismax = null; //指定X轴最大值，null时为自动 var autocolor = 1; //是否自动判断颜色，0为否，1根据品牌生成颜色 ，如果 >1 则为AMD NV Intel 标准色, var mycolor = []; //自动生成随机颜色 也可ANIColor("NVIDIA",3)可以生成三种NV绿，可替换成AMD Intel //var mycolor = ANIColor('AMD',4); //这样自动生成4种AMD红色，其它如NVIDIA、Intel同理 //var mycolor=['#953f61', '#72355f', '#d77169']; //自定义颜色 AMD红 '#9F1417', NV绿 '#82B41B', Intel蓝 '#0075C5', var mycolor = ['#0dcc47', '#969696', '#6f7b80','5A94DF']; var data_arr = [ {"type":"Time Spy","NVIDIA RTX 3060 Ti Founder Edition":"11723","影驰 RTX 3060 Ti 金属大师 OC":"11828","NVIDIA RTX 3070 Founder Edition":"13434","NVIDIA RTX 2080 SUPER Founder Edition":"11267","NVIDIA RTX 2060 SUPER Founder Edition":"8572"}, {"type":"Time Spy Extreme","NVIDIA RTX 3060 Ti Founder Edition":"5691","影驰 RTX 3060 Ti 金属大师 OC":"5772","NVIDIA RTX 3070 Founder Edition":"6637","NVIDIA RTX 2080 SUPER Founder Edition":"5245","NVIDIA RTX 2060 SUPER Founder Edition":"4063"}] TDInit(title_text, subtitle_text, unit_text, leftside, topside, mblur, bgopacity, mysort, myper, mylengend, toplegend, labelcolor, legendwidth, titlecolor, barheight, bargap, mycolor, data_arr, autocolor, xaxismax);预览var title_text = "3DMark Benchmark（DX 11）"; // 标题文字热管 var subtitle_text = "www.expreview.com | 数值越大越好 "; // 副标题文字 var unit_text = "分 "; //单位 var leftside = "8%"; //左边空白 var topside = 50; //每组间距 var mblur = 0.05; //模糊效果 var bgopacity = 0; //背景透明度，0为全透明 var mysort = 0; //是否排序 var myper = 1; //是否显示百分比 var mylengend = true; //是否显示图例 var toplegend = 50; //图例上端空白 var labelcolor = '#fff'; // 标签文字颜色 var legendwidth = '90%'; //图例宽度 var titlecolor = '#222'; //标题文字颜色 var barheight = 35; //柱高度,当为7倍数时，不显示刻度线 var bargap = 3; //柱间距,相当于百分值，即2% var xaxismax = null; //指定X轴最大值，null时为自动 var autocolor = 1; //是否自动判断颜色，0为否，1根据品牌生成颜色 ，如果 >1 则为AMD NV Intel 标准色, var mycolor = []; //自动生成随机颜色 也可ANIColor("NVIDIA",3)可以生成三种NV绿，可替换成AMD Intel //var mycolor = ANIColor('AMD',4); //这样自动生成4种AMD红色，其它如NVIDIA、Intel同理 //var mycolor=['#953f61', '#72355f', '#d77169']; //自定义颜色 AMD红 '#9F1417', NV绿 '#82B41B', Intel蓝 '#0075C5', //var mycolor = ['#0dcc47', '#969696', '#6f7b80','5A94DF']; var data_arr = [ {"type":"Fire Strike","NVIDIA RTX 3060 Ti Founder Edition":"28557","影驰 RTX 3060 Ti 金属大师 OC":"29349","NVIDIA RTX 3070 Founder Edition":"33166","NVIDIA RTX 2080 SUPER Founder Edition":"27921","NVIDIA RTX 2060 SUPER Founder Edition":"22012"}, {"type":"Fire Strike Extreme","NVIDIA RTX 3060 Ti Founder Edition":"13741","影驰 RTX 3060 Ti 金属大师 OC":"14253","NVIDIA RTX 3070 Founder Edition":"15728","NVIDIA RTX 2080 SUPER Founder Edition":"13157","NVIDIA RTX 2060 SUPER Founder Edition":"10365"}, {"type":"Fire Strike Ultra","NVIDIA RTX 3060 Ti Founder Edition":"7055","影驰 RTX 3060 Ti 金属大师 OC":"7267","NVIDIA RTX 3070 Founder Edition":"8199","NVIDIA RTX 2080 SUPER Founder Edition":"6573","NVIDIA RTX 2060 SUPER Founder Edition":"5150"} ]; TDInit(title_text, subtitle_text, unit_text, leftside, topside, mblur, bgopacity, mysort, myper, mylengend, toplegend, labelcolor, legendwidth, titlecolor, barheight, bargap, mycolor, data_arr, autocolor, xaxismax);预览var title_text = "3DMark Benchmark（Ray Tracing）"; // 标题文字热管 var subtitle_text = "www.expreview.com | 数值越大越好 "; // 副标题文字 var unit_text = "分 "; //单位 var leftside = "8%"; //左边空白 var topside = 50; //每组间距 var mblur = 0.05; //模糊效果 var bgopacity = 0; //背景透明度，0为全透明 var mysort = 0; //是否排序 var myper = 1; //是否显示百分比 var mylengend = true; //是否显示图例 var toplegend = 50; //图例上端空白 var labelcolor = '#fff'; // 标签文字颜色 var legendwidth = '90%'; //图例宽度 var titlecolor = '#222'; //标题文字颜色 var barheight = 35; //柱高度,当为7倍数时，不显示刻度线 var bargap = 3; //柱间距,相当于百分值，即2% var xaxismax = null; //指定X轴最大值，null时为自动 var autocolor = 1; //是否自动判断颜色，0为否，1根据品牌生成颜色 ，如果 >1 则为AMD NV Intel 标准色, //var mycolor = []; //自动生成随机颜色 也可ANIColor("NVIDIA",3)可以生成三种NV绿，可替换成AMD Intel //var mycolor = NIColor('AMD',4); //这样自动生成4种AMD红色，其它如NVIDIA、Intel同理 var mycolor=['#953f61', '#72355f', '#d77169']; //自定义颜色 AMD红 '#9F1417', NV绿 '#82B41B', Intel蓝 '#0075C5', var mycolor = ['#0dcc47', '#969696', '#6f7b80','5A94DF']; var data_arr = [ {"type":"Port Royal","NVIDIA RTX 3060 Ti Founder Edition":"6850","影驰 RTX 3060 Ti 金属大师 OC":"6943","NVIDIA RTX 3070 Founder Edition":"8064","NVIDIA RTX 2080 SUPER Founder Edition":"6879","NVIDIA RTX 2060 SUPER Founder Edition":"5003"} ]; TDInit(title_text, subtitle_text, unit_text, leftside, topside, mblur, bgopacity, mysort, myper, mylengend, toplegend, labelcolor, legendwidth, titlecolor, barheight, bargap, mycolor, data_arr, autocolor, xaxismax);从以上的成绩可以看出来，RTX 3060 Ti的定位就是在RTX 3070之下，在RTX 2060 SUPER之上。在目前的RTX 30系显卡里面，RTX 3060 Ti的成绩与RTX 3070相比相差了13%左右，而与上代同等级别的RTX 2060 SUPER相比，RTX 3060 Ti就要平均领先35%了。

游戏性能测试接下来我们看看实际的游戏表现。RTX 3060 Ti的定位，是2K分辨率的最佳显卡，因此我们的游戏测试都是在2K分辨率之下测试的。先来看一下传统光栅化游戏的表现。

预览var title_text = "2K 传统光栅化游戏测试"; // 标题文字热管 var subtitle_text = "www.expreview.com | 数值越大越好 "; // 副标题文字 var unit_text = "fps"; //单位 var leftside = "8%"; //左边空白 var topside = 50; //每组间距 var mblur = 0.05; //模糊效果 var bgopacity = 0; //背景透明度，0为全透明 var mysort = 0; //是否排序 var myper = 1; //是否显示百分比 var mylengend = true; //是否显示图例 var toplegend = 50; //图例上端空白 var labelcolor = '#fff'; // 标签文字颜色 var legendwidth = '90%'; //图例宽度 var titlecolor = '#222'; //标题文字颜色 var barheight = 35; //柱高度,当为7倍数时，不显示刻度线 var bargap = 3; //柱间距,相当于百分值，即2% var xaxismax = null; //指定X轴最大值，null时为自动 var autocolor = 1; //是否自动判断颜色，0为否，1根据品牌生成颜色 ，如果 >1 则为AMD NV Intel 标准色, var mycolor = []; //自动生成随机颜色 也可ANIColor("NVIDIA",3)可以生成三种NV绿，可替换成AMD Intel //var mycolor = ANIColor('AMD',4); //这样自动生成4种AMD红色，其它如NVIDIA、Intel同理 //var mycolor=['#953f61', '#72355f', '#d77169']; //自定义颜色 AMD红 '#9F1417', NV绿 '#82B41B', Intel蓝 '#0075C5', var mycolor = ['#0dcc47', '#969696', '#6f7b80','5A94DF']; var data_arr = [ {"type":"地铁：离去","影驰 RTX 3060Ti 金属大师 OC":"71.31","NVIDIA RTX 2080 SUPER Founder Edition":"70.31"}, {"type":"古墓丽影：暗影","影驰 RTX 3060Ti 金属大师 OC":"100","NVIDIA RTX 2080 SUPER Founder Edition":"97"}, {"type":"德军总部：新血脉","影驰 RTX 3060Ti 金属大师 OC":"179","NVIDIA RTX 2080 SUPER Founder Edition":"174"}, {"type":"无主之地 3","影驰 RTX 3060Ti 金属大师 OC":"68.25","NVIDIA RTX 2080 SUPER Founder Edition":"66.83"}, {"type":"刺客信条：英灵殿","影驰 RTX 3060Ti 金属大师 OC":"61","NVIDIA RTX 2080 SUPER Founder Edition":"60"}, {"type":"尘埃 5","影驰 RTX 3060Ti 金属大师 OC":"68.4","NVIDIA RTX 2080 SUPER Founder Edition":"69.9"}, {"type":"战争机器 5","影驰 RTX 3060Ti 金属大师 OC":"98","NVIDIA RTX 2080 SUPER Founder Edition":"96"}, {"type":"全面战争：三国","影驰 RTX 3060Ti 金属大师 OC":"59.4","NVIDIA RTX 2080 SUPER Founder Edition":"61.6"}, {"type":"Far Cry 5","影驰 RTX 3060Ti 金属大师 OC":"117","NVIDIA RTX 2080 SUPER Founder Edition":"116"}, {"type":"看门狗：军团","影驰 RTX 3060Ti 金属大师 OC":"61","NVIDIA RTX 2080 SUPER Founder Edition":"60"}]; TDInit(title_text, subtitle_text, unit_text, leftside, topside, mblur, bgopacity, mysort, myper, mylengend, toplegend, labelcolor, legendwidth, titlecolor, barheight, bargap, mycolor, data_arr, autocolor, xaxismax);在我们选取的10传统光栅化款游戏中有8款RTX 3060 Ti都是有领先优势的，幅度在1-5帧左右。最高的是《德军总部：新血脉》，最低的是《看门狗：军团》。而在《尘埃5》以及《全面战争：三国》中RTX 3060 Ti的帧数就稍微落后1-2帧。

预览var title_text = "2K 光追游戏测试"; // 标题文字热管 var subtitle_text = "www.expreview.com | 数值越大越好 "; // 副标题文字 var unit_text = "fps"; //单位 var leftside = "8%"; //左边空白 var topside = 50; //每组间距 var mblur = 0.05; //模糊效果 var bgopacity = 0; //背景透明度，0为全透明 var mysort = 0; //是否排序 var myper = 1; //是否显示百分比 var mylengend = true; //是否显示图例 var toplegend = 50; //图例上端空白 var labelcolor = '#fff'; // 标签文字颜色 var legendwidth = '90%'; //图例宽度 var titlecolor = '#222'; //标题文字颜色 var barheight = 35; //柱高度,当为7倍数时，不显示刻度线 var bargap = 3; //柱间距,相当于百分值，即2% var xaxismax = null; //指定X轴最大值，null时为自动 var autocolor = 1; //是否自动判断颜色，0为否，1根据品牌生成颜色 ，如果 >1 则为AMD NV Intel 标准色, var mycolor = []; //自动生成随机颜色 也可ANIColor("NVIDIA",3)可以生成三种NV绿，可替换成AMD Intel //var mycolor = ANIColor('AMD',4); //这样自动生成4种AMD红色，其它如NVIDIA、Intel同理 //var mycolor=['#953f61', '#72355f', '#d77169']; //自定义颜色 AMD红 '#9F1417', NV绿 '#82B41B', Intel蓝 '#0075C5', var mycolor = ['#0dcc47', '#969696', '#6f7b80','5A94DF']; var data_arr = [ {"type":"地铁：离去","影驰 RTX 3060Ti 金属大师 OC":"63.45","NVIDIA RTX 2080 SUPER Founder Edition":"62.54"}, {"type":"古墓丽影：暗影","影驰 RTX 3060Ti 金属大师 OC":"74","NVIDIA RTX 2080 SUPER Founder Edition":"75"}, {"type":"德军总部：新血脉","影驰 RTX 3060Ti 金属大师 OC":"184","NVIDIA RTX 2080 SUPER Founder Edition":"170"}, {"type":"光明记忆：无限","影驰 RTX 3060Ti 金属大师 OC":"74","NVIDIA RTX 2080 SUPER Founder Edition":"67"}, {"type":"边境","影驰 RTX 3060Ti 金属大师 OC":"68.5","NVIDIA RTX 2080 SUPER Founder Edition":"61.5"}, {"type":"看门狗：军团","影驰 RTX 3060Ti 金属大师 OC":"69","NVIDIA RTX 2080 SUPER Founder Edition":"66"}]; TDInit(title_text, subtitle_text, unit_text, leftside, topside, mblur, bgopacity, mysort, myper, mylengend, toplegend, labelcolor, legendwidth, titlecolor, barheight, bargap, mycolor, data_arr, autocolor, xaxismax);在光追游戏方面， RTX 3060 Ti跟RTX 2080 SUPER在老游戏跟新游戏的表现都不一样。像《地铁：离去》以及《古墓丽影：暗影》的老游戏，它们两个的差距并不明显，也就只有1帧左右的区别。但是在新游戏《看门狗：军团》以及《光明记忆：无限》的Benchmark里，RTX 3060 Ti跟RTX 2080 SUPER的差距就出来了，前者最高的领先幅度能到10%。

从以上的实际游戏表现看来RTX 3060 Ti确实是做到了RTX 2080 SUPER的水平，帧数差距基本是在误差范围。不过RTX 3060 Ti还是有一点优势的，那就是在新游戏，特别是开了光追的情况下，RTX 3060 Ti的帧数表现还是要领先RTX 2080 SUPER不少的。

温度、功耗、风扇转速及频率测试接下来我们看一下功耗跟温度的表现。影驰这张RTX 3060 Ti 金属大师 OC在室温为23度的环境下，平均待机功耗是15.6W，待机温度为平均36度，这时候显卡的风扇是不转的。

预览var title_text = "满载温度测试"; var subtitle_text = "www.expreview.com ｜数值越低越好"; var xname = "时间s"; //X轴单位 var yname = ["摄氏度"]; //Y轴1单位，Y轴2单位(如果有的话) var leftside = "8%"; //左边空白 var yax = 0; //是否双Y轴 var yminmax = [20, 90]; //Y轴最小值最大值，默认全0为自动，全1为自动以最小值数据最小值 var fill = 0; //0-1表示填充透明度 var sn = 5; //坐标轴分割为多少段 var mp = 1; //是否显示最大最小值 0为不显示 var symbolsize = 0; //数据点的大小，0为不显示 var autocolor = 0; //是否自动颜色 var colors = ['#5793f3', '#d14a61', '#675bba', '#A2CD5A']; var data_arr = [["0","待机 温度","满载 温度"],["1","35","35"],["2","35","35"],["3","35","35"],["4","35","36"],["5","35","35"],["6","35","36"],["7","35","36"],["8","35","36"],["9","35","35"],["10","35","35"],["11","35","35"],["12","35","35"],["13","35","36"],["14","35","36"],["15","35","35"],["16","35","35"],["17","35","35"],["18","35","35"],["19","35","37"],["20","35","46"],["21","35","50"],["22","35","51"],["23","35","52"],["24","35","52"],["25","35","53"],["26","35","54"],["27","35","54"],["28","35","54"],["29","35","54"],["30","35","54"],["31","35","55"],["32","35","56"],["33","35","56"],["34","35","55"],["35","35","56"],["36","35","56"],["37","35","56"],["38","35","56"],["39","35","57"],["40","35","57"],["41","35","57"],["42","35","57"],["43","35","57"],["44","35","58"],["45","35","58"],["46","35","58"],["47","35","58"],["48","35","59"],["49","35","59"],["50","35","59"],["51","35","60"],["52","35","60"],["53","35","60"],["54","35","60"],["55","35","61"],["56","36","61"],["57","35","60"],["58","35","60"],["59","36","61"],["60","35","61"],["61","35","61"],["62","36","61"],["63","36","62"],["64","36","62"],["65","36","62"],["66","36","62"],["67","36","62"],["68","36","62"],["69","36","62"],["70","36","62"],["71","36","63"],["72","36","63"],["73","36","63"],["74","36","63"],["75","36","64"],["76","36","64"],["77","36","63"],["78","36","64"],["79","36","64"],["80","36","64"],["81","36","64"],["82","36","64"],["83","36","64"],["84","36","64"],["85","36","65"],["86","36","65"],["87","36","64"],["88","36","65"],["89","36","65"],["90","36","65"],["91","36","65"],["92","36","65"],["93","36","65"],["94","36","65"],["95","36","65"],["96","36","65"],["97","36","65"],["98","36","65"],["99","36","65"],["100","36","65"],["101","36","65"],["102","36","65"],["103","36","65"],["104","36","65"],["105","36","66"],["106","36","65"],["107","36","65"],["108","36","65"],["109","36","65"],["110","36","65"],["111","36","66"],["112","36","65"],["113","36","65"],["114","36","66"],["115","36","65"],["116","36","66"],["117","36","66"],["118","36","65"],["119","36","65"],["120","36","66"],["121","36","66"],["122","36","66"],["123","36","66"],["124","36","66"],["125","36","66"],["126","36","66"],["127","36","65"],["128","36","65"],["129","36","65"],["130","36","66"],["131","36","66"],["132","36","66"],["133","36","65"],["134","36","66"],["135","36","66"],["136","36","65"],["137","36","66"],["138","36","66"],["139","36","66"],["140","36","66"],["141","36","66"],["142","36","65"],["143","36","66"],["144","36","66"],["145","36","66"],["146","36","66"],["147","36","66"],["148","36","65"],["149","36","66"],["150","36","66"],["151","36","66"],["152","36","66"],["153","36","66"],["154","37","66"],["155","37","66"],["156","36","66"],["157","37","66"],["158","37","66"],["159","36","66"],["160","37","66"],["161","37","65"],["162","37","66"],["163","37","66"],["164","37","66"],["165","37","66"],["166","37","66"],["167","37","66"]]; ZHXInit(title_text, subtitle_text, xname, yname, leftside, yax, fill, sn, colors, data_arr, mp, autocolor, yminmax, symbolsize);预览var title_text = "风扇转速"; var subtitle_text = "www.expreview.com ｜数值越高越好"; var xname = "时间s"; //X轴单位 var yname = ["RPM"]; //Y轴1单位，Y轴2单位(如果有的话) var leftside = "8%"; //左边空白 var yax = 0; //是否双Y轴 var yminmax = [1, 1]; //Y轴最小值最大值，默认全0为自动，全1为自动以最小值数据最小值 var fill = 0; //0-1表示填充透明度 var sn = 5; //坐标轴分割为多少段 var mp = 1; //是否显示最大最小值 0为不显示 var symbolsize = 0; //数据点的大小，0为不显示 var autocolor = 0; //是否自动颜色 var colors = ['#5793f3', '#d14a61', '#675bba', '#A2CD5A']; var data_arr = [["0","满载风扇转速"],["1","990"],["4","990"],["7","989"],["10","989"],["13","992"],["16","990"],["19","989"],["22","977"],["25","988"],["28","986"],["31","990"],["34","989"],["37","988"],["40","993"],["43","988"],["46","991"],["49","992"],["52","990"],["55","989"],["58","991"],["61","987"],["64","991"],["67","991"],["70","999"],["73","1016"],["76","1052"],["79","1082"],["82","1113"],["85","1134"],["88","1160"],["91","1180"],["94","1192"],["97","1205"],["100","1221"],["103","1228"],["106","1237"],["109","1246"],["112","1258"],["115","1267"],["118","1271"],["121","1275"],["124","1279"],["127","1285"],["130","1285"],["133","1295"],["136","1295"],["139","1298"],["142","1304"],["145","1304"],["148","1302"],["151","1307"],["154","1314"],["157","1317"],["160","1316"],["163","1323"],["166","1316"],["169","1322"],["172","1325"],["175","1329"],["178","1332"],["181","1332"],["184","1334"],["187","1332"],["190","1337"],["193","1340"],["196","1338"],["199","1343"],["202","1342"],["205","1345"],["208","1345"],["211","1351"],["214","1345"],["217","1346"],["220","1352"],["223","1354"],["226","1354"],["229","1360"],["232","1356"],["235","1356"],["238","1360"],["241","1359"],["244","1360"],["247","1364"],["250","1365"],["253","1360"],["256","1370"],["259","1359"],["262","1368"],["265","1367"],["268","1372"],["271","1368"],["274","1368"],["277","1365"],["280","1373"],["283","1373"],["286","1376"],["289","1378"],["292","1375"],["295","1377"],["298","1373"],["301","1381"],["304","1381"],["307","1373"],["310","1375"],["313","1373"],["316","1383"],["319","1388"],["322","1382"],["325","1383"],["328","1385"],["331","1383"],["334","1386"],["337","1386"],["340","1388"],["343","1390"],["346","1386"],["349","1390"],["352","1386"],["355","1390"],["358","1393"],["361","1391"],["364","1391"],["367","1395"],["370","1398"],["373","1391"],["376","1395"],["379","1395"],["382","1402"],["385","1398"],["388","1400"],["391","1398"],["394","1395"],["397","1398"],["400","1395"],["403","1408"],["406","1402"],["409","1398"],["412","1405"],["415","1402"],["418","1405"],["421","1403"],["424","1408"],["427","1405"],["430","1410"],["433","1405"],["436","1412"],["439","1410"],["442","1410"],["445","1410"],["448","1410"],["451","1412"],["454","1415"],["457","1408"],["460","1415"],["463","1414"],["466","1415"],["469","1412"],["472","1415"],["475","1420"],["478","1410"],["481","1410"],["484","1417"],["487","1417"],["490","1417"],["493","1419"],["496","1414"],["499","1421"],["502","1419"],["505","1422"],["508","1419"],["511","1417"],["514","1424"],["517","1419"],["520","1419"],["523","1427"],["526","1426"],["529","1426"],["532","1421"],["535","1428"],["538","1428"],["541","1421"],["544","1436"],["547","1424"],["550","1431"],["553","1429"],["556","1431"],["559","1435"],["562","1431"],["565","1419"],["568","1431"],["571","1433"],["574","1431"],["577","1428"],["580","1426"],["583","1440"],["586","1436"],["589","1422"],["592","1426"],["595","1429"],["598","1442"],["601","1429"],["604","1436"],["607","1426"],["610","1433"],["613","1429"],["616","1433"],["619","1436"],["622","1438"],["625","1435"]]; ZHXInit(title_text, subtitle_text, xname, yname, leftside, yax, fill, sn, colors, data_arr, mp, autocolor, yminmax, symbolsize);预览var title_text = "功耗测试"; var subtitle_text = "www.expreview.com ｜数值越低越好"; var xname = "时间s"; //X轴单位 var yname = ["W"]; //Y轴1单位，Y轴2单位(如果有的话) var leftside = "8%"; //左边空白 var yax = 0; //是否双Y轴 var yminmax = [0, 0]; //Y轴最小值最大值，默认全0为自动，全1为自动以最小值数据最小值 var fill = 0; //0-1表示填充透明度 var sn = 5; //坐标轴分割为多少段 var mp = 1; //是否显示最大最小值 0为不显示 var symbolsize = 0; //数据点的大小，0为不显示 var autocolor = 0; //是否自动颜色 var colors = ['#5793f3', '#d14a61', '#675bba', '#A2CD5A']; var data_arr = [["0","待机功耗","满载功耗"],["1","15.234","234.528"],["2","15.633","215.088"],["3","14.36","214.96"],["4","14.175","238.389"],["5","18.473","200.04"],["6","16.011","221.691"],["7","15.146","217.221"],["8","15.526","190.572"],["9","15.428","228.953"],["10","15.162","222.922"],["11","15.04","248.854"],["12","15.032","195.356"],["13","16.118","215.417"],["14","15.34","208.436"],["15","18.473","226.728"],["16","16.011","223.354"],["17","14.167","208.916"],["18","14.854","214.038"],["19","16.41","217.171"],["20","15.728","194.67"],["21","15.331","223.813"],["22","16.377","204.871"],["23","15.332","219.35"],["24","14.563","223.579"],["25","18.666","198.006"],["26","14.942","198.187"],["27","15.049","241.152"],["28","16.716","229.984"],["29","15.234","212.243"],["30","15.146","204.406"],["31","15.234","218.891"],["32","16.011","228.848"],["33","16.311","239.038"],["34","15.825","244.769"],["35","17.602","196.25"],["36","15.614","221.059"],["37","14.943","218.91"],["38","14.264","240.894"],["39","15.526","218.806"],["40","15.949","220.036"],["41","15.04","221.186"],["42","15.451","205.474"],["43","14.866","205.243"],["44","14.274","198.209"],["45","18.86","201.79"],["46","16.593","207.923"],["47","16.214","207.92"],["48","15.914","193.832"],["49","15.428","208.911"],["50","15.623","209.906"],["51","15.137","217.451"],["52","14.644","229.347"],["53","15.332","228.813"],["54","15.244","236.324"],["55","18.279","213.51"],["56","15.137","226.416"],["57","14.361","226.704"],["58","14.856","222.586"],["59","15.728","201.46"],["60","16.69","212.027"],["61","15.827","218.034"],["62","15.815","217.447"],["63","14.361","225.234"],["64","15.526","224.945"],["65","18.872","224.049"],["66","15.04","219.074"],["67","15.534","225.708"],["68","14.943","211.948"],["69","14.943","215.287"],["70","14.774","226.091"],["71","14.458","215.132"],["72","14.369","217.604"],["73","17.282","219.265"],["74","16.118","206.343"],["75","17.128","210.151"],["76","15.515","217.814"],["77","15.623","235.054"],["78","15.527","217.498"],["79","15.631","221.542"],["80","14.943","202.132"],["81","15.631","229.757"],["82","15.33","220.954"],["83","14.361","224.116"],["84","14.369","209.494"],["85","18.761","209.107"],["86","15.34","233.705"],["87","16.408","201.282"],["88","15.526","208.155"],["89","14.846","214.825"],["90","15.526","211.916"],["91","15.623","237.876"],["92","15.419","200.445"],["93","15.72","232.024"],["94","15.534","238.204"],["95","17.989","252.347"],["96","15.33","216.381"],["97","14.66","203.401"],["98","14.555","259.392"],["99","15.049","207.053"],["100","15.728","234.51"],["101","16.813","221.893"],["102","15.323","178.342"],["103","16.012","224.165"],["104","15.137","208.096"],["105","18.589","224.166"],["106","15.428","232.647"],["107","15.631","220.97"],["108","15.331","237.581"],["109","15.236","256.316"],["110","15.236","236.183"],["111","15.049","252.102"],["112","15.245","240.161"],["113","15.728","203.587"],["114","15.924","216.403"],["115","17.31","200.109"],["116","15.137","204.674"],["117","15.137","225.314"],["118","15.536","203.465"],["119","14.945","239.806"],["120","15.234","244.966"],["121","15.34","197.977"],["122","15.342","221.037"],["123","15.721","222.625"],["124","16.487","223.299"],["125","18.483","221.346"],["126","15.527","224.384"],["127","16.205","227.233"],["128","15.631","216.831"],["129","15.623","203.795"],["130","15.331","201.758"],["131","15.04","217.169"],["132","15.128","210.006"],["133","15.447","215.532"],["134","15.438","235.638"],["135","18.763","234.233"],["136","15.331","237.02"],["137","15.342","224.039"],["138","14.264","217.502"],["139","14.555","225.848"],["140","16.311","210.192"],["141","16.02","224.897"],["142","15.025","207.162"],["143","15.234","216.144"],["144","15.623","216.194"],["145","18.579","216.55"],["146","15.621","226.553"],["147","15.621","212.61"],["148","14.845","214.594"],["149","15.72","201.015"],["150","15.624","225.325"],["151","14.361","218.189"],["152","14.851","208.186"],["153","15.631","217.853"],["154","16.312","227.945"],["155","17.506","210.65"],["156","15.234","200.174"],["157","15.72","214.156"],["158","14.749","211.702"],["159","14.652","205.375"],["160","15.233","218.772"],["161","15.428","228.181"],["162","14.846","220.183"],["163","15.852","240.708"],["164","14.856","213.066"],["165","18.388","205.165"],["166","15.04","212.039"],["167","15.73","231.247"],["168","16.118","229.833"],["169","15.04","224.296"],["170","15.04","217.373"]]; ZHXInit(title_text, subtitle_text, xname, yname, leftside, yax, fill, sn, colors, data_arr, mp, autocolor, yminmax, symbolsize);而在以Time Spy Extreme满载运行的时候，显卡平均满载功耗达到218W，峰值功耗高达260W，风扇平均转速达到1400转，显卡最高温度在66度左右。这个功耗表现确实符合官方宣称的220W TGP，散热能力也达到了主流显卡应有的水平，使用起来，噪音也不会太高。当然了，这是开放平台测试出来的数据，实际使用的时候，温度还是会高一点的。

预览var title_text = "满载平均频率"; var subtitle_text = "www.expreview.com ｜数值越低越好"; var xname = "时间s"; //X轴单位 var yname = ["MHz"]; //Y轴1单位，Y轴2单位(如果有的话) var leftside = "8%"; //左边空白 var yax = 0; //是否双Y轴 var yminmax = [0, 2100]; //Y轴最小值最大值，默认全0为自动，全1为自动以最小值数据最小值 var fill = 0; //0-1表示填充透明度 var sn = 5; //坐标轴分割为多少段 var mp = 1; //是否显示最大最小值 0为不显示 var symbolsize = 0; //数据点的大小，0为不显示 var autocolor = 0; //是否自动颜色 var colors = ['#5793f3', '#d14a61', '#675bba', '#A2CD5A']; var data_arr = [["0","满载平均频率"],["1","2025"],["4","1935"],["7","1965"],["10","1965"],["13","1965"],["16","1950"],["19","1965"],["22","1965"],["25","1950"],["28","1950"],["31","1950"],["34","1935"],["37","1950"],["40","1935"],["43","1935"],["46","1935"],["49","1950"],["52","1935"],["55","1920"],["58","1935"],["61","1935"],["64","1920"],["67","1935"],["70","1935"],["73","1920"],["76","1920"],["79","1935"],["82","1920"],["85","1920"],["88","1935"],["91","1935"],["94","1935"],["97","1920"],["100","1935"],["103","1920"],["106","1920"],["109","1920"],["112","1920"],["115","1920"],["118","1920"],["121","1920"],["124","1920"],["127","1935"],["130","1920"],["133","1920"],["136","1920"],["139","1935"],["142","1920"],["145","1920"],["148","1935"],["151","1935"],["154","1920"],["157","1935"],["160","1935"],["163","1935"],["166","1920"],["169","1935"],["172","1920"],["175","1920"],["178","1935"],["181","1920"],["184","1905"],["187","1935"],["190","1920"],["193","1920"],["196","1920"],["199","1920"],["202","1920"],["205","1920"],["208","1920"],["211","1935"],["214","1920"],["217","1935"],["220","1920"],["223","1920"],["226","1920"],["229","1920"],["232","1920"],["235","1920"],["238","1935"],["241","1935"],["244","1905"],["247","1935"],["250","1935"],["253","1920"],["256","1920"],["259","1935"],["262","1920"],["265","1920"],["268","1920"],["271","1920"],["274","1920"],["277","1935"],["280","1920"],["283","1905"],["286","1920"],["289","1935"],["292","1920"],["295","1920"],["298","1935"],["301","1935"],["304","1905"],["307","1935"],["310","1935"],["313","1920"],["316","1920"],["319","1935"],["322","1920"],["325","1920"],["328","1935"],["331","1935"],["334","1920"],["337","1935"],["340","1920"],["343","1920"],["346","1920"],["349","1920"],["352","1920"],["355","1920"],["358","1920"],["361","1935"],["364","1920"],["367","1920"],["370","1920"],["373","1920"],["376","1920"],["379","1920"],["382","1920"],["385","1920"],["388","1920"],["391","1935"],["394","1920"],["397","1935"],["400","1920"],["403","1920"],["406","1920"],["409","1935"],["412","1920"],["415","1920"],["418","1935"],["421","1950"],["424","1905"],["427","1935"],["430","1920"],["433","1920"],["436","1920"],["439","1920"],["442","1920"],["445","1905"],["448","1920"],["451","1920"],["454","1920"],["457","1935"],["460","1935"],["463","1920"],["466","1920"],["469","1920"],["472","1920"],["475","1935"],["478","1920"],["481","1935"],["484","1905"],["487","1935"],["490","1920"],["493","1935"],["496","1920"],["499","1920"],["502","1920"],["505","1920"],["508","1920"],["511","1935"],["514","1905"],["517","1935"],["520","1905"],["523","1920"],["526","1920"],["529","1920"],["532","1920"],["535","1920"],["538","1920"],["541","1935"],["544","1920"],["547","1935"],["550","1935"]]; ZHXInit(title_text, subtitle_text, xname, yname, leftside, yax, fill, sn, colors, data_arr, mp, autocolor, yminmax, symbolsize);我们刚刚也说过，这是一张OC的显卡，所以频率是要高一点的。在满载运行的时候，影驰RTX 3060 Ti 金属大师 OC的平均频率是在1920MHz左右。

超频性能测试大家都知道，RTX30系的显卡基本上出厂即灰烬了，那么它还有没有超频空间呢？我们顺便折腾了一下这张影驰的RTX 3060 Ti 金属大师 OC，在核心频率加130MHz，显存频率增加300MHz的情况下，显卡可以通过3D MARK的各项测试，成绩的增幅达到了3.8%左右，也说明了手动超频的性价比确实不高。

预览var title_text = "超频测试 3DMark Benchmark（DX12）"; // 标题文字热管 var subtitle_text = "www.expreview.com | 数值越大越好 "; // 副标题文字 var unit_text = "分 "; //单位 var leftside = "8%"; //左边空白 var topside = 50; //每组间距 var mblur = 0.05; //模糊效果 var bgopacity = 0; //背景透明度，0为全透明 var mysort = 0; //是否排序 var myper = 1; //是否显示百分比 var mylengend = true; //是否显示图例 var toplegend = 50; //图例上端空白 var labelcolor = '#fff'; // 标签文字颜色 var legendwidth = '90%'; //图例宽度 var titlecolor = '#222'; //标题文字颜色 var barheight = 35; //柱高度,当为7倍数时，不显示刻度线 var bargap = 3; //柱间距,相当于百分值，即2% var xaxismax = null; //指定X轴最大值，null时为自动 var autocolor = 1; //是否自动判断颜色，0为否，1根据品牌生成颜色 ，如果 >1 则为AMD NV Intel 标准色, //var mycolor = []; //自动生成随机颜色 也可ANIColor("NVIDIA",3)可以生成三种NV绿，可替换成AMD Intel var mycolor = ANIColor('AMD',4); //这样自动生成4种AMD红色，其它如NVIDIA、Intel同理 //var mycolor=['#953f61', '#72355f', '#d77169']; //自定义颜色 AMD红 '#9F1417', NV绿 '#82B41B', Intel蓝 '#0075C5', var mycolor = ['#0dcc47', '#969696', '#6f7b80','5A94DF']; var data_arr = [ {"type":"Time Spy","影驰 RTX 3060 Ti 金属大师 OC  默频":"11828","影驰 RTX 3060 Ti 金属大师 OC 超频":"12251"}, {"type":"Time Spy Extreme","影驰 RTX 3060 Ti 金属大师 OC  默频":"5772","影驰 RTX 3060 Ti 金属大师 OC 超频":"6009"}, ]; TDInit(title_text, subtitle_text, unit_text, leftside, topside, mblur, bgopacity, mysort, myper, mylengend, toplegend, labelcolor, legendwidth, titlecolor, barheight, bargap, mycolor, data_arr, autocolor, xaxismax);预览var title_text = "超频测试 3DMark Benchmark（DX11）"; // 标题文字热管 var subtitle_text = "www.expreview.com | 数值越大越好 "; // 副标题文字 var unit_text = "分 "; //单位 var leftside = "8%"; //左边空白 var topside = 50; //每组间距 var mblur = 0.05; //模糊效果 var bgopacity = 0; //背景透明度，0为全透明 var mysort = 0; //是否排序 var myper = 1; //是否显示百分比 var mylengend = true; //是否显示图例 var toplegend = 50; //图例上端空白 var labelcolor = '#fff'; // 标签文字颜色 var legendwidth = '90%'; //图例宽度 var titlecolor = '#222'; //标题文字颜色 var barheight = 35; //柱高度,当为7倍数时，不显示刻度线 var bargap = 3; //柱间距,相当于百分值，即2% var xaxismax = null; //指定X轴最大值，null时为自动 var autocolor = 1; //是否自动判断颜色，0为否，1根据品牌生成颜色 ，如果 >1 则为AMD NV Intel 标准色, //var mycolor = []; //自动生成随机颜色 也可ANIColor("NVIDIA",3)可以生成三种NV绿，可替换成AMD Intel var mycolor = ANIColor('AMD',4); //这样自动生成4种AMD红色，其它如NVIDIA、Intel同理 //var mycolor=['#953f61', '#72355f', '#d77169']; //自定义颜色 AMD红 '#9F1417', NV绿 '#82B41B', Intel蓝 '#0075C5', var mycolor = ['#0dcc47', '#969696', '#6f7b80','5A94DF']; var data_arr = [ {"type":"Fire Strike","影驰 RTX 3060 Ti 金属大师 OC  默频":"29349","影驰 RTX 3060 Ti 金属大师 OC 超频":"30206"}, {"type":"FireStrike Extreme","影驰 RTX 3060 Ti 金属大师 OC  默频":"14253","影驰 RTX 3060 Ti 金属大师 OC 超频":"14755"}, {"type":"FireStrike Ultra","影驰 RTX 3060 Ti 金属大师 OC  默频":"7267","影驰 RTX 3060 Ti 金属大师 OC 超频":"7500"}, ]; TDInit(title_text, subtitle_text, unit_text, leftside, topside, mblur, bgopacity, mysort, myper, mylengend, toplegend, labelcolor, legendwidth, titlecolor, barheight, bargap, mycolor, data_arr, autocolor, xaxismax);预览var title_text = "超频测试 3DMark Benchmark（Ray-Tracing）"; // 标题文字热管 var subtitle_text = "www.expreview.com | 数值越大越好 "; // 副标题文字 var unit_text = "分 "; //单位 var leftside = "8%"; //左边空白 var topside = 50; //每组间距 var mblur = 0.05; //模糊效果 var bgopacity = 0; //背景透明度，0为全透明 var mysort = 0; //是否排序 var myper = 1; //是否显示百分比 var mylengend = true; //是否显示图例 var toplegend = 50; //图例上端空白 var labelcolor = '#fff'; // 标签文字颜色 var legendwidth = '90%'; //图例宽度 var titlecolor = '#222'; //标题文字颜色 var barheight = 35; //柱高度,当为7倍数时，不显示刻度线 var bargap = 3; //柱间距,相当于百分值，即2% var xaxismax = null; //指定X轴最大值，null时为自动 var autocolor = 1; //是否自动判断颜色，0为否，1根据品牌生成颜色 ，如果 >1 则为AMD NV Intel 标准色, //var mycolor = []; //自动生成随机颜色 也可ANIColor("NVIDIA",3)可以生成三种NV绿，可替换成AMD Intel var mycolor = ANIColor('AMD',4); //这样自动生成4种AMD红色，其它如NVIDIA、Intel同理 //var mycolor=['#953f61', '#72355f', '#d77169']; //自定义颜色 AMD红 '#9F1417', NV绿 '#82B41B', Intel蓝 '#0075C5', var mycolor = ['#0dcc47', '#969696', '#6f7b80','5A94DF']; var data_arr = [ {"type":"Port Royal","影驰 RTX 3060 Ti 金属大师 OC  默频":"6943","影驰 RTX 3060 Ti 金属大师 OC 超频":"7330"} ]; TDInit(title_text, subtitle_text, unit_text, leftside, topside, mblur, bgopacity, mysort, myper, mylengend, toplegend, labelcolor, legendwidth, titlecolor, barheight, bargap, mycolor, data_arr, autocolor, xaxismax);总结这张RTX 3060 Ti，确实做到了RTX 2080 SUPER的水平。以主流的价格买到上一代的中高端性能，它的性价比还是不错的。换一个角度来说，用2K 60帧来玩游戏的标准已经是平民化了，至少买一张RTX 3060 Ti来玩2K游戏是没有压力的。

我们手上这张影驰的RTX 3060 Ti 金属大师 OC可能就是其中一个比较好的选择。特别是对于非RGB玩家来说，它没有半点RGB灯效而且外观也不差，简洁有质感，加上3风扇的设计，又能保持良好的散热效能。而其3199的价格，也对得起主流级别的称呼了。

当然, 今晚我们还有公版RTX 3060 Ti的首发评测, 有兴趣的朋友可以点以下连接观看：《GeForce RTX 3060 Ti天梯榜首发评测：没有敌手的主流级游戏卡》

在配置上的选择呢，这里也是给一个思路，大家可以灵活变通，比如你是一名内容创造者，你需要更多的CPU核心，那你完全可以把CPU更换为Intel Core i9-10900K处理器，当然如果是游戏党的话其实Intel Core i7-10700K在帧数已经是与Intel Core i9-10900K相差无几了，性价比更高一些。我们其余的配件选择原因在视频中都有讲到，感兴趣的朋友赶紧点开下方的视频看看吧！

视频带有简体中文字幕，但需要到bilibili网站使用新版播放器查看，另外原站点可以支持最大4K分辨率播放，画质更佳，推荐使用。

if (IsMobile()) { jQuery("iframe").attr("width", "100%"); jQuery("iframe").attr("height", jQuery("#post_body").width() * 9 / 16); } else jQuery("iframe").attr("height", jQuery("#post_body").width() * 9 / 16 + 120);手机通道：哔哩哔哩

预览var istart = 1; //通过编号生成，图片开始的编号，不强求连续，但尽量连续编号，小图+s，如1s； // var istart=['1','2','3','4','5','6']; //通过文件名生成，大图文件名，不含后缀，小图以s结尾 var ilast = 19; //结束图片的编号，如果是文件名生成，这个数字不用改 var tips = []; //图片说明，按顺序列，没有就空着 var iurl = "https://img.expreview.com/review/2020/09/yc3090ns/"; //图片目录 var col = 3; //列数，一排几张图，1 2 3 4可选 var nomore = 0; //大小图是否一样，1为一样，不需要s后缀的小图，用于列图片 var gap = 0; //图片间距修正，默认0 var bd = 0; //描边，0或1，默认0 var full = 0; //是否全屏，0 或 1 var pic = ".jpg"; //图片格式 WaterInit(pic, iurl, col, gap, bd, istart, ilast, full, tips, nomore);GAMER系列是影驰多年的老牌系列了，定位在中高端，不过从这张影驰RTX 3090 GAMER来看，这个老牌系列在这一代上玩出了很青春洋气的气息。首先从影驰RTX 3090 GAMER的用色可以很容易的让人联想到任天堂Switch，其次，仔细看表面会发现影驰RTX 3090 GAMER采用了积木的元素设计，可以搭配积木尽情的DIY。

正面有3个大风扇，均为90mm的规格，每个风扇的扇叶均达到了11片，而且扇叶都经过了特殊的空气动力学设计，同转速下可以达到更好的散热效能。背面可以看到巨大的金属背板，也用了任天堂Switch的经典红蓝色，显得很有年轻范儿，很有活力。背板的末端部分有大面积的镂空，也是增加散热效能的设计。

影驰RTX 3090 GAMER仍然是三槽厚度的设计，这可以从档板那一面看得出来，不过影驰还有送一个双槽的挡板，对于某些机箱或许用得上，此外这里还可以看到显示接口是3个DP接口和1个HDMI接口，当然这个HDMI接口是2.1规格的。供电接口方面，可以看到影驰RTX 3090 GAMER是双8Pin的供电接口，与公版一样。

除了是三槽厚度之外，影驰RTX 3090 GAMER拿到手的第一感觉还会觉得它特别长，经过测量这张卡达到了340mm，真的是一个巨无霸一样的家伙，所以它也有送显卡支撑杆，需要玩家自己组装一下就可以。此外，这一代的RTX 30系显卡看起来也就RTX 3090还具有NVLink SLI功能了，在影驰RTX 3090 GAMER上可以看到新一代的NVLink接口。

if (IsMobile()) { jQuery("iframe").attr("width", "100%"); jQuery("iframe").attr("height", jQuery("#post_body").width() * 9 / 16); } else jQuery("iframe").attr("height", jQuery("#post_body").width() * 9 / 16 + 120);除此之外，影驰RTX 3090 GAMER还有个很大的亮点是支持ARGB灯效，可以与主板控制的ARGB灯效系统同步，在这张卡的顶端后面可以看到ARGB的4pin接口，并且显卡有送ARGB的连接线，将ARGB的连接线一端接到这个4pin接口另一端插到主板上的ARGB端子上，就可以进行灯效同步的设定。
